Drilling Tools l Drilling Accessories l Plate Nut Drill Jigs l One Lug-Single Wing Standard (SWS)
 |
Part Number |
Bolt Size Ref. |
Spacing A |
Pilot Diameter C |
Drill Size D |
AT518G |
#6 |
.344 |
.139 |
#40 |
AT518H |
#8 |
.164 |
||
AT518J |
#10 |
.191 |
||
AT518K |
1/4 |
.248 |
||
AT518RM |
#10 |
.1875 |
||
AT518RO |
1/4 |
.500 |
.248 |
|
AT518NAS-D-A5 |
5/16 |
.359 |
.312 |
#30 |
AT518NAS-D-A6 |
3/8 |
.414 |
.372 |
|
AT518RP |
5/16 |
.500 |
.3105 |
|
AT518RG |
.3145 |
|||
AT518FH |
.372 |
|||
AT518RH |
3/8 |
.373 |
||
AT518RJ |
7/16 |
.435 |
||
AT518RB |
#6 |
.344 |
.1425 |
#40 |
AT518RL |
#8 |
.1645 |
||
AT518RC |
.1675 |
|||
AT518RD |
#10 |
.192 |
||
AT518L |
.213 |
|||
AT518RU |
#8 |
.2265 |
||
AT518RE |
1/4 |
.2555 |
||
AT518LF |
#8/#10 |
.2810 |
||
AT518RW |
1/4 |
.3105 |
||
AT518RF |
.500 |
.2555 |
||
AT518RX |
.3105 |
|||
AT518YF |
.343 |
